Manufacturer no.:
562826
Modular Trabon® MXP distribution valve with indicator - MXP-75T - 0.075 in³ (1.23 cm³)
€319.16*
% €354.62* (10% saved)Ready for shipping in 5-8 days
Also interesting
Product information
The Trabon MXP series offers the largest outlet available in a progressive system. It can be easily equipped with cycle indicators with magnetic and electronic proximity switches to confirm successful lubrication.
This makes it ideal for challenging and large bearing applications with a wide temperature range and high-volume requirements.
- The Quick-Change valve segments can be removed from the base unit without disconnecting the lubrication lines. This minimises labour costs and increases machine uptime.
- Optional outlets can be fitted with indicator pins for easier troubleshooting – no more guesswork when it comes to fault finding
- Nearly indestructible rugged construction for use in the most extreme environments
| Artikel Art: | Verteiler |
|---|
More information
- Product number: 1037537
- Manufacturer: Graco
- EAN: 00633955360594
- Weight: 1.246 kg
- Length: 160 mm
- Width: 35 mm
- Height: 45 mm
Technical details
Operating specifications
| UPC product | 633955360594 |
|---|---|
| Division | LED |
| Price Block | 125 |
| Country of origin | US |
| Unit of measurement | EA |
| Height | 4 .5 CM |
| Length | 16 cm |
| Width | 3 .5 cm |
| Volume | 0 M3 |
| Shipping weight | 1 .25 kg |
Technical
| Maximum cycle rate (cycles/min) | 60 |
|---|---|
| Maximum working pressure (psi) | 3000 |
| Minimum working pressure (psi) | 2 00 |
| Number of outlets | 2 |
| Maximum working pressure (bar) | 2 07 |
| Maximum operating temperature (°F) | 350 |
| Maximum working pressure (kPa) | 2 0 700 |
| Maximum NLGI grade | #2 |
| Maximum operating temperature (°C) | 1 76 |
| Divider Valve Series | MXP |
| Model | Trab on |
| Series | MXP |
| Discharge per piston stroke (in³) | N/A |
