MarSurf M 310 mobile roughness measuring device
Scope of delivery
The compact handheld measuring device impresses with its simple operation, integrated evaluation and a comprehensive set of accessories – ideal for flexible use directly on the machine or in the measuring room.
Functionality & advantages
The MarSurf M 310 works with a precise probe system and enables
standard-compliant roughness measurements in accordance with common international standards.
Measurements are taken using a feed device with a removable probe,
which allows even hard-to-reach measuring points to be reliably tested.
Your advantages at a glance:
• Mobile, handy roughness measuring device
• Standard-compliant measurements with 2 µm probe tip
• Integrated rechargeable battery for mains-independent use
• Clearly structured display of measurement results
• Ideal for production, quality assurance and service
Scope of delivery of the SET
The MarSurf M 310 SET – 2 µm is supplied as a fully equipped measuring system:
• MarSurf M 310 base unit
• Feed device (removable)
• Standard probe PHT6-350, compliant with standards
• 2 µm probe tip
• Built-in rechargeable battery
• Roughness standard, integrated into the housing (removable)
• Calibration certificate from Mahr
• Probe protection (prism holder)
• Probe protection with attachment prism
• Height adjustment (integrated)
• Charger / mains adapter
• Operating instructions
• Carrying case with shoulder strap
• USB cable
• Hand prism with height adjustment (pair)
• Extension cable for feed device (length 1.2 m)
Typical areas of application
• Roughness measurement in production
• Quality assurance and final inspection
• Incoming goods inspection
• Measurements close to the machine
• Service and maintenance assignments
- Product number: 2181601
- Manufacturer: Mahr
Technical details
| Produkt | MarSurf M 310 SET |
| Tastspitze | 2 µm |
| Messsystem | Mobiles Rauheitsmessgerät |
| Taster | PHT6-350 (normgerecht) |
| Einsatz | Fertigung & Qualitätssicherung |
