Manufacturer no.: 563222

Trabon® replacement pressure gauge, 1/8-27 NPSF with O-ring, 317 bar (4600 psi)

€71.40*

€60.00*

Price excl. VAT

Ready for shipping in 5-8 days

EU B2B: net prices with valid VAT ID

Also interesting

Product information

For applications with MH diverting valve when lubrication system pressures exceed 2500 psi.

High pressure caused by blockages leads to disc breakage
Lubricant pushes out an indicator pin, revealing the blockage
High pressure continues backwards through the system and triggers a switch that shuts down the system
Once the fault has been rectified, the disc must be replaced and the pin reset

Application:	Machines in manufacturing plants, compressor devices
Compatible material:	oil
Connection dimensions (inch):	125
Indicator type:	Overpressure indicator
Maximum operating pressure (MPa):	32
Maximum operating pressure (kPa):	31700
Maximum operating pressure (psi):	4600
Model:	Trabon
Permissible operating pressure (bar):	317
Thread type:	NPSF
Total length (cm):	4
Total length (mm):	45
Total width (cm):	1.4224
Total width (mm):	14,224
Type:	Notice of discharge

More information

Technical details

Connection size (in)	0. 125
Maximum working pressure (bar)	3 17
Maximum working pressure (kPa)	3 1 700
Maximum working pressure (psi)	4 6 00
Overall Width (mm)	14,22 4
Overall Length (cm)	4
Overall Length (in)	1. 77
Overall Length (mm)	45
Overall Width (cm)	1. 4224
Overall width (in)	0. 56
Maximum Working Pressure (MPa)	32
Model	Trab on
