Manufacturer no.: JS30L0

High-Flo 4-ball pump, stainless steel, 3:1, low-noise exhaust air system, bottom pump with open oil cup, Tri-Clamp fittings, Ultralife rod/cylinder

€13,495.10*

% €17,301.41* (22% saved)

Prices include VAT plus shipping costs

€11,340.42*

Price excl. VAT

Ready for shipping in 5-8 days

14 days free exchange

Free shipping within Germany

EU B2B: net prices with valid VAT ID

Also interesting

Product information

The pneumatic High-Flo 4-ball piston pump enables a high flow rate per cycle and minimises wear and maintenance requirements of the pump. Ideal for low pressure, high flow applications; intrinsically safe in hazardous areas.

Unlike many rotary pump technologies, slow up and down movements ensure that colour quality is not compromised
Robust casing that will not rust or dent
De-icing monitoring prevents the motor from stalling
The ceramic coating of the Ultralife series resists even the most aggressive materials, such as water-based paints

Application:	circulation
Compatible material:	Water Based, Solvent Based, High Solids, Xirallic, Metal, Top Coats, Stains, Lacquer, CARC
Includes:	Stainless steel pump, low-noise exhaust system, tri-clamp fittings, Ultralife rod, Ultralife cylinder
Material:	stainless steel
Material outlet size (cm):	3.81
Material outlet size (mm):	38.1
Material section type:	Open oil cup
Maximum air supply pressure (bar):	6.9
Maximum air supply pressure (kPa):	690
Maximum continuous double stroke rate (DH/min):	12
Maximum delivery rate (L/min):	87.82
Maximum inlet air pressure (psi):	100
Maximum operating pressure (MPa):	2.1
Maximum operating pressure (kPa):	2100
Maximum operating pressure (psi):	300
Maximum operating temperature (°C):	66
Model:	High Flo
Motor type:	Quiet NXT
Permissible operating pressure (bar):	21
Portable:	Not portable
Series:	4-Ball
Size of the material outlet opening (inches):	1-1/2
Transmission ratio of the pump:	3:1
Type:	Pneumatic piston pump
Wetted material:	stainless steel

More information

Product number: 1036357
Manufacturer: Graco
EAN: 00755652323068
Weight: 62.5 kg
Length: 1550 mm
Width: 440 mm
Height: 520 mm

Technical details

Specifications

Operating specifications

UPC product	755652323068
Division	IPD
Price Block	029
Country of Origin	US
Unit	EA
Height	52 CM
Length	155 cm
Width	44 cm
Volume	. 355 m³
Shipping weight	62.5 KG

Technical

Fluid outlet size (mm)	38. 1
Includes	Stainless steel pump, low noise exhaust, Tri-Clamp fittings, Ultralife rod, Ultralife cylinder
Maximum Air Inlet Pressure (bar)	6. 9
Maximum air inlet pressure (kPa)	690
Maximum air inlet pressure (psi)	100
Maximum continuous cycle rate (CPM)	12
Maximum flow rate (L/min)	87. 82
Maximum operating temperature (°C)	66
Maximum operating temperature (°F)	1 5 0
Maximum working pressure (bar)	2 1
Maximum working pressure (kPa)	2 100
Maximum working pressure (psi)	300
Model	High-Flo
Portable	Non-portable
Series	4-Ball
Maximum Working Pressure (MPa)	2. 1
