Manufacturer no.:
XM5D00
Graco - XM SPRAYING DEVICE SYSTEM XM50,BF,R,IS - Protective coatings, 2K devices - XM5D00
€53,003.03*
% €61,452.79* (13.75% saved)
Also interesting
Product information
The Graco Waste multi-component sprayer
Advanced, intuitive user controls provide real-time ratio display
USB port allows easy access and download of historical spray data
Supports multiple spray guns for added productivity
Graco is a globally recognised manufacturer of fluid handling systems and components. services for various industries. Graco's high-quality products are used for paints, coatings, lubricants, sealants, adhesives and building materials. With decades of expertise, Graco offers innovative solutions for efficient material handling and optimised coating applications and precise dispensing technology.
More information
- Product number: 2147442
- Manufacturer: Graco
- EAN: 633955420113
- Weight: 403.17 kg
- Length: 11 mm
- Width: 10.5 mm
- Height: 19.5 mm
Technical details
Operating specifications
| UPC product | 633955420113 |
|---|---|
| Division | CED |
| Price Block | 228 |
| Country of origin | US |
| Unit | EA |
| Height | 195 CM |
| Length | 110 CM |
| Width | 105 CM |
| Volume | 2 .252 m³ |
| Shipping weight | 403.17 kg |
Technical
| 20 gal heated hopper method | None |
|---|---|
| Air inlet size (in) | 3/ |
| Air inlet thread gender | Female |
| Component Type | Plural Component |
| Feed Pumps | None |
| Fluid inlet size (in) | 1-1/4 |
| Fluid inlet thread gender | Male |
| Includes | Whip Hose, Static Mixer, XTR Spray Gun |
| Location Category | Hazardous Location |
| Material Application | Coatings, paints, primers |
| Maximum Air Consumption (SCFM) | 70 scfm/gpm at 100 psi |
| Maximum air inlet pressure (bar) | 10. 34 |
| Maximum air inlet pressure (kPa) | 1 0 34 |
| Maximum air inlet pressure (psi) | 150 |
| Maximum flow rate (cc/min) | 11360 |
| Maximum flow rate (L/min) | 11. 36 |
| Maximum fluid temperature (°C) | 71 |
| Maximum fluid temperature (°F) | 160 |
| Maximum fluid viscosity (cP) | 2 0 000 |
| Maximum Mix Ratio | 10: 1 |
| Maximum operating temperature (°C) | 57 |
| Maximum operating temperature (°F) | 1 35 |
| Maximum spray pressure (bar) | 3 44 |
| Maximum spray pressure (kPa) | 3 4400 |
| Maximum spray pressure (MPa) | 34 |
| Maximum spray pressure (psi) | 5 0 00 |
| Maximum working pressure (bar) | 358 |
| Maximum working pressure (kPa) | 3 5 800 |
| Maximum working pressure (MPa) | 35. 8 |
| Maximum working pressure (psi) | 5 2 00 |
| Minimum flow rate (cc/min) | 9 5 0 |
| Minimum flow rate (GPM) | 0. 25 |
| Minimum flow rate (L/min) | 0. 95 |
| Minimum fluid viscosity (cP) | 2 00 |
| Minimum mix ratio | 1: 1 |
| Number of tanks | 0 |
| Overall height (cm) | 177. 8 |
| Overall height (in) | 70 |
| Overall height (mm) | 1778 |
| Primary fluid heater included | No |
| Product Type | Plural Component |
| Pump filter included | Yes |
| Remote Mix Manifold Included | Yes |
| Sound pressure level (dB(A)) | 86 |
| Supply Hoppers | None |
| Maximum air inlet pressure (MPa) | 1. 03 |
| Series | XM50 |
Further manufacturer information
312796.pdf |313632S, Handbuch, NXT Druckluftmotor, Anleitungen und Ersatzteile, Deutsch |Deutsch |Revision S
312796.pdf |313633R, Manual, Motor neumtico NXT, Instucciones y Piezas, Espaol |Spanisch |Revision S
312796.pdf |313631S, Moteur pneumatique NXT, Instructions et Pices manual, Franais |Franzsisch |Revision S
312359.pdf |3A0008NL-V, Handleiding, XM-meercomponentenspuittoestellen, Bediening, Nederlands |Niederlndisch |Revision LATEST
312359.pdf |3A0016SV-V, handbok, XM-flerkomponentssprutor, drift, svenska |Schwedisch |Revision LATEST
312359.pdf |3B0220PT-V, Manual, Pulverizadores de mltiplos componentes XM, Funcionamento, Portugus |Portugiesisch |Revision LATEST
312359.pdf |312359EN-V, Manual, XM Plural-Component Sprayers, Operation, English |Englisch |Revision LATEST
312359.pdf |3A0011IT-V, Manuale, Spruzzatori multicomponente XM, Funzionamento, italiano |Italienisch |Revision LATEST
312359.pdf |3A1446PT-V, Klavuz, XM ok Komponentli Pskrtme Makineleri, alma, Trke |Trkisch |Revision LATEST
312359.pdf |3A0015ES-V, Manual, Pulverizadores multicomponente XM, Funcionamiento, espaol |Spanisch |Revision LATEST
312359.pdf |3A0009FR-V, manuel, pulvrisateurs multi-composants XM, fonctionnement, franais |Franzsisch |Revision LATEST
312359.pdf |3A0010DE-V, Handbuch XM Mehrkomponenten-Spritzgerte, Betrieb, Deutsch |Deutsch |Revision LATEST
312359.pdf |3A8212PL-V, Instrukcja, Urz dzenia do natryskiwania wieloskadnikowego XM, Obsuga, polski |Polnisch |Revision LATEST
312359.pdf |3A6934RO-V, Manual, Pulverizator cu mai multe componente XM, operare, romn |Rumnisch |Revision LATEST
307892.pdf |307892K -Back Pressure Valve with Carbide Needle and Seat, Instructions-Parts List, English |Englisch |Revision K
307892.pdf |333247K, Instructions-Parts Manual for Back Pressure Valve with Carbide Needle and Seat, Portuguese |Portugiesisch |Revision K
3A7469.pdf |3A7510DE-F, Handbuch, ,XTR5+ und XTR7+Airless-Spritzpistole, Anleitung, Deutsch |Deutsch |Revision LATEST
3A7469.pdf |3A7469EN-F, Manual, XTR5+ and XTR7+ Airless Spray Gun, Instructions, English |Englisch |Revision LATEST
3A7469.pdf |3A7512NL-F, Handleiding, Airless spuitpistolen XTR5+ en XTR7+, Instructies, Nederlands |Niederlndisch |Revision LATEST
3A7469.pdf |3A7513PL-F, Podrcznik, Pistolet do natrysku hydrodynamicznego XTR5+ i XTR7+, Instrukcje, jzyk polski |Polnisch |Revision LATEST
3A7469.pdf |3A7516SV-F, Handbok, XTR5+ och XTR7+ airless-sprutpistol, Anvisningar, Svenska |Schwedisch |Revision LATEST
3A7469.pdf |3A7511IT-F, Manuale, Pistola a spruzzo airless XTR5+ e XTR7+, Istruzioni, Italiano |Italienisch |Revision LATEST
3A7469.pdf |3A7509FR-F, Manuel, Pistolets pulvrisateurs Airless XTR5+ et XTR7+, Instructions, Franais |Franzsisch |Revision LATEST
3A7469.pdf |3A7517TR-F, Klavuz, XTR5+ ve XTR7+ Havasz Pskrtme tabancas, Talimatlar, Trke |Trkisch |Revision LATEST
3A7469.pdf |3A7514PT-F, Manual, Pistolas pulverizadoras sem ar XTR5+ e XTR7+, Instrues, Portugus |Portugiesisch |Revision LATEST
3A7469.pdf |3A7508ES-F, Manual, Pistola de pulverizacin airless XTR5+ y XTR7+, Instrucciones, Espaol |Spanisch |Revision LATEST
