Manufacturer no.:
WMC53F3
Graco - THERM-O-FLOW SUPPLY UNIT,68:1ACS,D200S-200A,240V,N - Sealant & Adhesive,1K Units - WMC53F3
€27,576.64*
% €31,972.00* (13.75% saved)Prices include VAT plus shipping costs
€23,173.65*
Price excl. VAT
Also interesting
Product information
THERM-O-FLOW SUPPLY UNIT,68:1ACS,D200S-200A,240V,N - Sealants & Adhesives,1K Devices
The Graco THERM-O-FLOW SUPPLY UNIT,68:1ACS,D200S-200A,240V,N from the category Sealants & Adhesives,1K Equipment is a high-quality spare part with the manufacturer number WMC53F3. It is perfect for applications in industrial coating, painting technology and other professional applications.
Product features
- Manufactured by Graco - leading supplier of surface technology
- Ideal for sealants & adhesives, 1K equipment
- High durability and precision
- Easy to install and maintain
Applications
The Graco THERM-O-FLOW SUPPLY UNIT,68:1ACS,D200S-200A,240V,N is often used in the following areas:
- Automotive industry
- Aerospace industry
- Industrial painting and coating systems
- General surface technology
About Graco
Graco is a leading global manufacturer of surface technology products. With decades of experience, Graco offers high-precision spraying and dispensing systems used in automotive, aerospace and industrial coating applications.
Graco products are known for their high quality, reliability and durable construction. Thanks to innovative technologies, they are ideal for professional use in painting technology, powder coating and many other areas.
More information
- Product number: 2147148
- Manufacturer: Graco
Technical details
Operating specifications
| UPC product | 7 6 9946177633 |
|---|---|
| Division | IPD |
| Price Block | 2 22 |
| Country of Origin | US |
| Unit | EA |
| Height | 0 CM |
| Length | 0 CM |
| Width | 0 CM |
| Volume | 0 M3 |
| Shipping weight | 0 KG |
Technical
| Ambient/Warm Melt/Hot Melt | Hot melt |
|---|---|
| Container Type | D rum |
| Material container volume (gal) | 55 |
| Material Container Volume (l) | 2 00 |
| Maximum air inlet pressure (bar) | 9 |
| Maximum air inlet pressure (psi) | 125 |
| Maximum air inlet pressure (MPa) | 0. 9 |
| Maximum flow rate (L/min) | 12 |
| Maximum fluid pressure (bar) | 3 45 |
| Maximum fluid pressure (MPa) | 34. 5 |
| Maximum fluid pressure (psi) | 5 0 00 |
| Maximum height (in) | 125 |
| Maximum height (mm) | 3 1 75 |
| Maximum operating temperature (°C) | 70 |
| Maximum operating temperature (°F) | 158 |
| Maximum working pressure (bar) | 3 44 |
| Maximum working pressure (MPa) | 34. 4 |
| Minimum Height (in) | 96 |
| Minimum height (mm) | 2 4 38 |
| Model | Ther m- O-Flow |
| Overall Depth (in) | 25 |
| Overall depth (mm) | 635 |
| Overall Width (in) | 45 |
| Overall width (mm) | 1 1 43 |
| Series | Warm Melt |
| Weight (kg) | 362 |
| Air inlet size (in) | 3/ |
| Air inlet thread gender | Female |
| Amperage (A) | 16 |
| Control Options | No Advanced Display Module |
| Fluid outlet thread gender | Female |
| Input Cycle Rate (Hz) | 50/60 |
| Lower Type | Check-Mate MaxLife |
| Maximum Ambient Temperature (°C) | 4 9 |
| Maximum ambient temperature (°F) | 120 |
| Maximum fluid temperature (°C) | 70 |
| Maximum fluid temperature (°F) | 158 |
| Maximum voltage (V ac) | 2 4 0 |
| Minimum ambient temperature (°C) | 0 |
| Minimum ambient temperature (°F) | 32 |
| Minimum flow rate (cc/min) | 1 2 000 |
| Minimum voltage (V ac) | 2 00 |
| Number of wipers | Double Ring |
| Ram post diameter (mm) | 165. 1 |
| Ram post diameter (in) | 6. 5 |
| Pump & Plate | Ambi ent |
Further manufacturer information
311238.pdf |312377ZAT, Manuel, Moteur pneumatique NXT, Instructions-Pices, Franais |Franzsisch |Revision ZAT
311238.pdf |312378ZAT, Manual, Motor neumtico NXT, Instrucciones - Piezas, Espaol |Spanisch |Revision ZAT
311238.pdf |312386ZAT, Manual,Motor pneumtico NXT,Instrues-Peas, Portugus |Portugiesisch |Revision ZAT
311238.pdf |312387ZAT, Manuell, NXT luftmotor, Instruktioner-reservdelar, Swedish |Schwedisch |Revision ZAT
311238.pdf |312379ZAT, Handbuch, NXT-Druckluftmotor, Anleitungen - Teile, Deutsch |Deutsch |Revision ZAT
311238.pdf |312382ZAT, Manuale, Motore pneumatico NXT,IstruzioniParti, Italian |Italienisch |Revision ZAT
311238.pdf |311238ZAT, Manual, NXT Air Motor, Instructions-Parts List, English |Englisch |Revision ZAT
311238.pdf |312397ZAT, Podrcznik, Silnik pneumatyczny NXT, InstrukcjeCzoeci, Polski |Polnisch |Revision ZAT
310523.pdf |310523B, Luchtgedreven Ram, BEDIENINGSINSTRUCTIES - ONDERDELENLIJSTI, Dutch |Niederlndisch |Revision B
310523.pdf |310523B, FOR 200 LITERS FATSTORLEK MED 6--1/2" DUBBLA STOLPAR Luftdriven tryckmatare, RESERVDELSFORTECKNING, Swedish |Schwedisch |Revision B
310523.pdf |310523H, Ram Globale, Manuale distruzioni Elenco delle parti, Italian |Italienisch |Revision H
310523.pdf |310523H, Ensemble lvateur, Manuel dinstructions Liste des pices, French |Franzsisch |Revision H
310523.pdf |310523Y, Manual, Global Ram, 55 GALLON (200 LITER) DRUM SIZE, 61/2 DUAL POST, Instructions-Parts, English |Englisch |Revision Y
312375.pdf |332045P, Instrukcja, Pompy wyporowe CheckMate, Instrukcje czci, Polski |Polnisch |Revision P
312375.pdf |312706P, Handbuch,Check-Mate Unterpumpen, Anleitung - Teile, Deutsch |Deutsch |Revision P
312375.pdf |313132P,Pompe volumetriche Check-Mate,Istruzioni - Parti, Italiano |Italienisch |Revision P
312375.pdf |312709P, Bombas volumtricas Check-Mate, Instrues - Peas, Portugus |Portugiesisch |Revision P
312375.pdf |312710P, Bombas de desplazamiento Check-Mate, Instrucciones - Piezas, Espaol |Spanisch |Revision P
312375.pdf |3A8724R, Check-Mate kolvpumpar, Instruktioner reservdelar, svenska |Schwedisch |Revision R
312375.pdf |3A9443R, Handleiding, Onderpompen Check-Mate, Instructies/Onderdelen, Nederlands |Niederlndisch |Revision R
3A8005.pdf |3A8509C, Manual, Therm-O-Flow Warm Melt, Instrucciones-Piezas, espaol |Spanisch |Revision C
3A8005.pdf |3A8517C, pruka, systm tepl taveniny Therm-O-Flow, uivatelsk pruka s katalogem nhradnch soust, esky |Tschechisch |Revision C
3A8005.pdf |3A8515C, Instrukcja obsugi, Therm-O-Flow Warm Melt, instrukcje - czci, jzyk polski |Polnisch |Revision C
3A8005.pdf |3A8521C, Manual, Therm-O-Flow Warm Melt, Instrues-Peas, Portugus |Portugiesisch |Revision C
