Manufacturer no.: 17H473

The LineLazer V 250DC HP Reflective series, a petrol-powered hydraulic airless marking device with self-propelled drive, 2 automatic guns, 2 containers

Price on request

Prices include VAT plus shipping costs

Ready for shipping in 5-8 Werktage

14 days free exchange

Free shipping within Germany

Request price

Also interesting

Product information

The LineLazer V 250DC HP Reflective Series offers a highly productive two-colour marking capability and a reflective bead feature and is ideal for airports, municipalities, DOTs or any application with highlighted or two-colour lines with reflective beads.

The HP Reflective Series extends the functionality of the HP Automatic Series with superior bead application features that include automatic line making, including broken lines, and real-time application performance data for verification requirements.

Pressurised glass bead dispensing system
- Integrated encapsulated compressor prevents dust and dirt ingress
- Appropriate bead flow and colour penetration are ensured
- Large-volume bead container with a capacity of up to 54 kg
- The bead gun is automatically activated at the same time as the paint gun
- Bead gun with application delay function
- Adjustable nozzle for regulating the bead application width
For two colours
- Two-colour applications with just one single device for improved efficiency and profitability
Automatic colour gun system
- Button operation for reduced operator fatigue and accurate (broken) lines
- Manual, semi-automatic and fully automatic guns/mode
Two Graco hydraulic motors
- Hydraulic design that prevents downtime allows for uninterrupted operation
Endurance Chromex pump
- Durable pumps deliver precise flow for a variety of marking materials
- The industry's best pump performance with field-proven design.
- Handle the most demanding materials with a rod treated for longer durability - 4x harder than ordinary chrome
LiveLook display with SmartControl
- Track, measure and control every aspect of your job
- Real-time information for perfect lines
Two paint containers with 55 litre capacity
- - Longer marking jobs thanks to larger material container
Honda® GX390 engine
- Reliable and easy to start
- Favoured by users: outstanding performance and proven reliability
- Oil level warning shuts off the engine to prevent damage if the oil level drops too low
Front or rear gun holder
- Up to six guns can be mounted at the front and rear
- The front gun mount can be used for marking work up to the kerb, the rear gun mount to improve straightness and uniformity of long lines.
Additional features
- Self-centring front wheel
- High-performance cooling system
- Electric starter
- EasyMark gun adjustment system
- Easy adjustment of the handle bar
- Easy Out pump filter
- Flex Plus guns

Compatible material:	Colors for road markings
Compatible surfaces:	road, lawn
Container volume capacity (L):	114
Fuel tank capacity (L):	5.3
Gun activation:	2 Automatic
Maximum delivery rate (L/min):	9.5
Maximum nozzle size (cm):	991
Maximum nozzle size (inch):	39
Maximum nozzle size (mm):	9,906
Maximum operating pressure (kPa):	2270
Maximum operating pressure (psi):	3300
Maximum operating speed (km/h):	16.1
Maximum operating speed (mph):	10
Maximum sound pressure level (dB(A)):	89.1
Maximum speed (rpm):	3600
Model:	LineLazer V
Motor model:	GX390
Number of colours:	two-color
Number of containers:	2
Number of guns:	2
Number of pumps:	2
Permissible operating pressure (bar):	227
Product series:	HP Reflective
Pump type:	Endurance
Rated power (kW):	9.69
Series:	250DC
Supply voltage:	Petrol powered, hydraulic
Total height (cm):	141.5
Total height (mm):	1414.8
Total length (cm):	186.7
Total length (mm):	1866.9
Total width (cm):	83.8
Total width (mm):	838
Type:	Self-propelled line marking device
Weight (kg):	392

More information

Product number: 1038590
Manufacturer: Graco
EAN: 00755652320180
Weight: 453 kg
Length: 2000 mm
Width: 1140 mm
Height: 1600 mm
