Manufacturer no.:
M24200-GV1-B
Elcometer
Elcometer Performance – 24" 200 litre (610 mm, 7.06 cu ft) portable blast machine with 12 bar (174 psi), Kit 1 with General Valve
€4,054.33*
Scope of delivery
1 Stück
Also interesting
Product information
200 L high-performance pressure blasting machine for large-scale industrial applications
This 200 L pressure blasting machine with a 610 mm (24") pressure vessel has been specially developed for large-volume blasting work in industry, shipbuilding and construction. Whether as a basic kit or in a high-pressure configuration, it offers maximum performance, long service life and high efficiency.
Technical data at a glance
- Volume: 200 litres / 7.06 cu ft
- Tank diameter: 610 mm (24")
- Max. working pressure (standard): 12 bar (174 psi)
- Max. working pressure (high-pressure version): 15 bar (217 psi)
- Test pressure: up to 25.8 bar (375 psi)
- Steel wall: 6.3 mm thickness
- Water separator & remote control as standard
- CE & UKCA certified (according to PED 2014/68/EU)
Available variants & equipment
| Model | Working pressure | Dosing valve | Recommended use |
|---|---|---|---|
| Contractor Basic | 12 bar | Manual general valve | Standard blasting work, easy to maintain |
| Performance Kit 1 | 12 bar | Manual general valve | High performance for medium use |
| Performance Kit 1 Auto | 12 bar | Automatic general valve | Uniform material flow during continuous operation |
| Performance Kit 2 | 12 bar | Manual general valve | More accessories & modular expansion |
| Performance Kit 2 Auto | 12 bar | Automatic general valve | Ideal for continuous industrial processes |
| Performance HP Kit 1 | 15 bar | Manual general valve | For high-pressure tasks, e.g. on ships or concrete |
| Performance HP Kit 2 Auto | 15 bar | Automatic general valve | Maximum efficiency under the toughest conditions |
Areas of application
- Ship and offshore cleaning
- Concrete and bridge renovation
- Rust removal from large steel surfaces
- Blasting prior to painting
- Large-scale projects in refineries, petrochemical plants and power stations
Special features
- Extra large abrasive volume – ideal for long operations
- Expandable equipment options and kits
- Includes water separator, screen cover, safety labels
- Portable and suitable for mobile use
- Optimised for maximum media control & durability
PDF data sheet
Here is the official data sheet (PDF) for a technical overview and equipment details.
More information
- Product number: 2151747
- Manufacturer: Elcometer
- Weight: 202 kg
- Length: 1200 mm
- Width: 1000 mm
- Height: 1550 mm
