Manufacturer no.: 234272

Material regulator for low pressure, max. 580 psi, 6 to 145 psi, 7.0 gal/min, stainless steel, air type, 3/8 (f) x 3/8 (f), 1/8 BSPP connection

€1,098.61*

% €1,373.26* (20% saved)

€923.20*

Price excl. VAT

Ready for shipping in 5-8 days

EU B2B: net prices with valid VAT ID

Also interesting

Product information

Our pneumatically operated material pressure regulators are primarily designed for coating materials with high viscosity.

Actuation type:	Air
Diffuser size (cm):	9,525
Includes:	Just regulators
Inlet size (cm):	9,525
Inlet size (inch):	3/8
Inlet size (mm):	9,525
Inlet thread type:	NPT
Maximum delivery rate (L/min):	26.5
Maximum operating pressure (MPa):	4
Maximum operating pressure (kPa):	4000
Maximum operating pressure (psi):	580
Maximum regulated pressure (MPa):	1.0
Maximum regulated pressure (bar):	10
Maximum regulated pressure (kPa):	1000
Maximum regulated pressure (psi):	145
Maximum viscosity (cP):	1000
Minimum regulated pressure (MPa):	0.04
Minimum regulated pressure (bar):	0.4
Minimum regulated pressure (kPa):	40
Minimum regulated pressure (psi):	6
Outlet size (inch):	3/8
Outlet size (mm):	9,525
Permissible operating pressure (bar):	40
Pressure gauge opening:	BSPP(I)
Size of the pressure gauge opening (cm):	3,175
Size of the pressure gauge opening (inches):	1/8
Size of the pressure gauge opening (mm):	3,175
Type:	Material flow controller
Wetted material:	stainless steel

More information

Technical details

Actuation Type	Air
Gauge port size (cm)	0. 3175
Gauge port size (in)	1/8
Gauge port size (mm)	3. 175
Gauge port type	BSPP
Includes	Regulator only
Inlet Size (cm)	0. 9525
Inlet Size (in)	3/8
Inlet Size (mm)	9. 525
Maximum flow rate (L/min)	26. 5
Maximum Regulated Pressure (bar)	10
Maximum regulated pressure (kPa)	1 0 00
Maximum Regulated Pressure (psi)	1 45
Maximum viscosity (cP)	1 0 00
Maximum working pressure (bar)	40
Maximum working pressure (kPa)	4 0 00
Maximum working pressure (psi)	580
Minimum Regulated Pressure (bar)	0. 4
Minimum Regulated Pressure (kPa)	40
Minimum regulated pressure (psi)	6
Outlet Size (cm)	0. 9525
Outlet size (in)	3/8
Outlet size (mm)	9. 525
Maximum regulated pressure (MPa)	1
Maximum working pressure (MPa)	4
Minimum Regulated Pressure (MPa)	0. 04
