Manufacturer no.:
234267
Material regulator for low pressure, max. 1015 psi, 145 to 725 psi, 9.8 gal/min, stainless steel, air type, 3/8 (f) x 3/8 (f), 1/8 BSPP connection
€1,235.70*
% €1,544.62* (20% saved)Prices include VAT plus shipping costs
€1,038.40*
Price excl. VAT
Ready for shipping in 5-8 days
Also interesting
Product information
Mechanical material pressure regulators are primarily designed for spray materials with low to medium viscosity.
| Actuation type: | Feather |
|---|---|
| Diffuser size (cm): | 9,525 |
| Includes: | Just regulators |
| Inlet size (cm): | 9,525 |
| Inlet size (inch): | 3/8 |
| Inlet size (mm): | 9,525 |
| Inlet thread type: | NPT |
| Maximum delivery rate (L/min): | 37.1 |
| Maximum operating pressure (MPa): | 7 |
| Maximum operating pressure (kPa): | 7000 |
| Maximum operating pressure (psi): | 1015 |
| Maximum regulated pressure (MPa): | 5.0 |
| Maximum regulated pressure (bar): | 50 |
| Maximum regulated pressure (kPa): | 5000 |
| Maximum regulated pressure (psi): | 725 |
| Maximum viscosity (cP): | 1000 |
| Minimum regulated pressure (MPa): | 1.0 |
| Minimum regulated pressure (bar): | 10 |
| Minimum regulated pressure (kPa): | 1000 |
| Minimum regulated pressure (psi): | 145 |
| Outlet size (inch): | 3/8 |
| Outlet size (mm): | 9,525 |
| Permissible operating pressure (bar): | 70 |
| Pressure gauge opening: | BSPP(I) |
| Size of the pressure gauge opening (cm): | 3,175 |
| Size of the pressure gauge opening (inches): | 1/8 |
| Size of the pressure gauge opening (mm): | 3,175 |
| Type: | Material flow controller |
| Wetted material: | stainless steel |
More information
- Product number: 1035323
- Manufacturer: Graco
- EAN: 00633955040052
- Weight: 2.417 kg
- Length: 274 mm
- Width: 213 mm
- Height: 152 mm
Technical details
Operating specifications
| UPC product | 633955040052 |
|---|---|
| Division | IPD |
| Price Block | 093 |
| Country of Origin | US |
| Unit | EA |
| Height | 15.2 CM |
| Length | 27.4 CM |
| Width | 21.3 cm |
| Volume | . 009 M3 |
| Shipping weight | 2 .42 KG |
Technical
| Actuation type | Spring |
|---|---|
| Gauge Port Size (cm) | 0. 3175 |
| Gauge port size (in) | 1/8 |
| Gauge port size (mm) | 3. 175 |
| Gauge port type | BSPP |
| Includes | Regulator only |
| Inlet Size (cm) | 0. 9525 |
| Inlet size (in) | 3/8 |
| Inlet size (mm) | 9. 525 |
| Maximum flow rate (L/min) | 37. 1 |
| Maximum Regulated Pressure (bar) | 50 |
| Maximum regulated pressure (kPa) | 5 0 00 |
| Maximum Regulated Pressure (psi) | 725 |
| Maximum viscosity (cP) | 1 0 00 |
| Maximum working pressure (bar) | 70 |
| Maximum working pressure (kPa) | 7000 |
| Maximum working pressure (psi) | 1 0 15 |
| Minimum Regulated Pressure (bar) | 10 |
| Minimum Regulated Pressure (kPa) | 1 0 00 |
| Minimum Regulated Pressure (psi) | 1 45 |
| Outlet Size (cm) | 0. 9525 |
| Outlet size (in) | 3/8 |
| Outlet size (mm) | 9. 525 |
| Maximum regulated pressure (MPa) | 5 |
| Maximum working pressure (MPa) | 7 |
| Minimum regulated pressure (MPa) | 1 |
