The iQ Tip Seal Dispense Valve offers high reliability for single component sealant and adhesive dispensing applications.
Hersteller-Nr.:
VELLT200BB
Graco - IQ TIP SEAL VENTIL,EL,4.0/T,200,ADJ/SOL,WEL - Precision Flo Geraete und Ersatzteile - VELLT200BB
5.272,49 €*
% 6.113,00 €* (13.75% gespart)
Auch interessant
Produktinformationen
The iQ Tip Seal Dispense Valve offers high reliability for single component sealant and adhesive dispensing applications.
- Maximize dispense time while minimizing maintenance costs and effort
- Delivers precise, consistent dispensing with clean starts and stops
- Ideal for low to high viscosity materials
- Elite seal and hardened components extends life with abrasive materials
- Easy repeatable mounting for robotic and automated applications.
- 200mm nozzle is compatible with 200mm focal length vision systems
Weitere Informationen
- Produktnummer: 2147020
- Hersteller: Graco
Technische Details
Betriebsspezifikationen
| UPC Produkt | 769946271003 |
|---|---|
| Division | IPD |
| Price Block | 223 |
| Country of Origin | US |
| Maßeinheit | EA |
| Höhe | 16.5 CM |
| Länge | 46.5 CM |
| Breite | 11.5 CM |
| Volumen | .009 M3 |
| Shipping Weight | 1.94 KG |
| HTS-Code (GB) | 8481900090 |
| HTS-Code (EU) | 8481900090 |
Technische Daten
| Maximum Air Pressure (bar) | 8.3 |
|---|---|
| Maximum Air Pressure (psi) | 120 |
| Maximum Operating Temperature (°C) | 70 |
| Maximum Operating Temperature (°F) | 158 |
| Air Inlet Size (in) | 5/16 |
| Ambient/Warm Melt/Hot Melt | Warm Melt |
| Component Type | Single Component |
| Fluid Inlet Size (in) | 1/4 |
| Fluid Inlet Thread Gender | Female |
| Maximum Air Pressure (MPa) | 0.83 |
| Maximum Fluid Pressure (bar) | 276 |
| Maximum Fluid Pressure (MPa) | 28 |
| Maximum Fluid Pressure (psi) | 4000 |
| Nozzle Size (in) | 0.157 |
| Nozzle Size (mm) | 4 |
| Outlet Block Length (in) | 7.9 |
| Outlet Block Length (mm) | 200 |
| RTD Type | 100 OHM - Platinum |
| Solenoid Valve Voltage Rating (V dc) | 24 |
| Weight (kg) | 1.6 |
Weitere Herstellerinformationen
333585.pdf |3A7809G, Handleiding, iQ-doseerventielen, Instructies/Onderdelen, Nederlands |Niederlndisch |Revision G
333585.pdf |3A7807G instrukcja obsugi, zawory dozuj ce iQ, instrukcje czci, jzyk polski |Polnisch |Revision G
333585.pdf |3A7810G, handbok, iQ-utmatningsventiler, instruktioner och reservdelar, svenska |Schwedisch |Revision G
333585.pdf |3A7802G Manuale, Valvole di erogazione iQ, Istruzioni-Parti, italiano |Italienisch |Revision G
333585.pdf |3A7808G, Manual, Vlvula de distribuio IQ, Instrues - Peas, Portugus |Portugiesisch |Revision G
333585.pdf |3A7806G pruka, uivatelsk pruka s katalogem nhradnch soust pro dvkovac ventily iQ, esky |Tschechisch |Revision G
333585.pdf |333585EN-R, Manual, iQ Dispense Valves, Instructions-Parts, English |Englisch |Revision LATEST
