Manufacturer no.:
PT56414112
Elcometer
Product hose for regular materials with 3/4" female thread connection: 10 m (36.1 ft)
€126.81*
% €140.00* (9.42% saved)
Also interesting
Product information
ProLine standard material hose for regular materials – 10 m, ¾" female thread
The ProLine standard material hose has been specially developed for pumping conventional materials such as solvent-based or water-based paints, primers and coatings. With a length of 10 metres and a ¾" female thread connection, it is ideal for use with pressure vessels such as the P30B and P60B.
Technical features:
- Length: 10 m (32.8 ft)
- Inner/outer diameter: 19 mm / 26 mm (0.75" / 1.02")
- Material: EPDM rubber (inside), textile reinforcement (outside)
- Colour: Black
- Temperature range: -40°C to +120°C
- Maximum operating pressure: 20 bar (290 psi)
- Burst pressure: 60 bar (870 psi)
- Connection: ¾" female thread (BSP IG)
Advantages
- High resistance to abrasion and chemicals
- Flexible and easy to handle
- Suitable for use in paint booths and industrial environments
- Compatible with ProLine P30B and P60B pressure vessels
Scope of delivery:
- 1x ProLine standard material hose, 10 m
- 2x ¾" female thread connections
- 1x operating instructions (PDF link)
PDF operating instructions:
The complete instructions for safe commissioning and maintenance can be found here:
View/download PDF now
More information
- Product number: 2150773
- Manufacturer: Elcometer
- Weight: 3 kg
- Width: 400 mm
- Height: 150 mm
