ProLine P60B stainless steel pressure vessel – 60 L with castors and double bottom drain

The ProLine P60B is a large-volume stainless steel pressure vessel with a capacity of 60 litres (15.85 US gallons). The robust construction, combined with a double bottom drain, allows two spray guns to be connected simultaneously and ensures an even, continuous supply of material – ideal for professional painting and finishing processes in industrial environments.

Technical features:

• Tank volume: 60 litres (15.85 US gallons)
• Construction: Stainless steel (tank and lid) – corrosion-resistant & easy to clean
• Outlet: 2x bottom connection for parallel material delivery
• Operating pressure: max. 7 bar (101 psi)
• Temperature range: 0–50 °C
• Pressure gauge: Pressure indicator for air and material
• Safety valve: factory-set
• Mobility: Heavy-duty castors with locking function
• Connections: 3/8" BSP (product), 1/4" BSP (air)

Special advantages:

• Excellent for high-volume painting and multi-gun operation
• High-quality stainless steel construction for durability and hygiene
• CE compliant, ATEX-approved with appropriate installation
• Uniform material flow thanks to low-lying double outlet
• Maximum mobility thanks to stable castors with locking mechanism

Areas of application:

• Vehicle construction & industrial painting
• Mechanical engineering & metalworking
• Adhesive processing & resin application
• Continuous operation in automated paint shops

Overview of variants:

Scope of delivery:

• 1x stainless steel pressure vessel 60 L
• 1x safety lid with clamp fastener
• 2x material outlets at the bottom
• 1x pressure regulator with pressure gauge
• 1x safety valve
• 1x Mounted castors
• 1x operating instructions (PDF link)

PDF operating instructions:

The complete instructions for safe commissioning and maintenance can be found here:
View/download PDF now
