3nh Colour Light Cabinet – Model P60+ – Light source: D65, TL84, F, UV, CWF, TL83
€547.40*
Scope of delivery
The P60+ colour inspection booth with 6 light sources is the updated version of the P60 series and enables precise visual colour assessment under standardised lighting conditions. It is ideally suited for colour-critical applications in printing, textiles, plastics, coatings, packaging, leather, the automotive industry and other industrial sectors.
System & Application
The P60+ colour inspection booth provides consistent viewing conditions for the reliable assessment of colour deviations and metamerism effects. By combining multiple light sources, colours can be inspected under different lighting conditions and assessed with confidence.
Light sources
D65 – Standard daylight, 6500 K
TL84 – Retail lighting (Europe/Asia), 4000 K
CWF – Cool white fluorescent light, 4150 K
TL83 – European retail lighting, 3000 K
F – Warm light / sunset light, 2700 K
UV – UV light for testing optical brighteners and fluorescent pigments, 365 nm
Technical specifications
Model: P60+
Light sources: D65, TL84, UV, F, CWF, TL83
Dimensions (W × D × H): 695 × 552 × 502 mm
Internal dimensions (W × D × H): 665 × 490 × 360 mm
Voltage: 220 V
Weight: 19.5 kg
Special features
6 different light sources for detecting metamerism
Separate switches for each light type
Automatic switching between light sources
Operating hours counter to monitor the optimal time for lamp replacement
No warm-up time and no flickering
Low heat generation and energy-efficient operation
Suitable for standard-compliant visual colour assessment
- Product number: 2200083
- Manufacturer: 3nh
