Manufacturer no.:
243012
SG3 metal spray gun
€348.08*
% €428.40* (18.75% saved)Ready for shipping in 5-8 days
Also interesting
Product information
This spray gun is well balanced and lightweight. It has a 4-finger full trigger for a comfortable spraying experience. With a TrueAirless 515 spray nozzle and a spray nozzle guard.
Smooth Glide hose swivel joint
- Avoids twisted hoses
- For efficient spraying work with the gun
Colour filter in the handle
- Easily accessible design
- Prevents clogged nozzles and improves the finish
4-finger full trigger
- Release for flushing and cleaning
- To avoid fatigue, the trigger is 30% smoother than conventional guns
| Actuation lock: | Lock |
|---|---|
| Compatible material: | Water-based paint, solvent-based paints |
| Component type: | Single component |
| For use with: | Project Painter Plus, X5, X7, ProX17 stand, ProX17 chassis, ProX19 stand, ProX19 chassis, ProX21 stand, ProX21 chassis |
| Fume cupboard type: | Four-finger |
| Gun activation: | Hand- |
| Gun type: | Airless spray gun |
| Gun weight (oz): | 22 |
| Includes: | TrueAirless 515 spray nozzle, spray nozzle guard, Smooth Glide swivel |
| Maximum material pressure (MPa): | 24.8 |
| Maximum material pressure (bar): | 248 |
| Maximum material pressure (kPa): | 24800 |
| Maximum material pressure (psi): | 3600 |
| Model: | SG3 |
| Nozzle opening size (inches): | 125 |
| Rinsing method: | liquid |
| Series: | Airless gun |
| Size of the material opening (cm): | 318 |
| Size of the material opening (mm): | 3.17 |
| Total height (cm): | 20.32 |
| Total height (mm): | 203.2 |
| Total length (cm): | 4,445 |
| Total length (mm): | 44.45 |
| Total width (cm): | 12.7 |
| Total width (mm): | 127 |
| Type: | spray gun |
More information
- Product number: 1035635
- Manufacturer: Graco
- EAN: 00633955916326
- Weight: 0.664 kg
- Length: 280 mm
- Width: 210 mm
- Height: 95 mm
Technical details
Operating specifications
| UPC product | 6 3 3955916326 |
|---|---|
| Division | CED |
| Price Block | 094 |
| Country of origin | US |
| Unit | EA |
| Height | 9 .5 CM |
| Length | 28 cm |
| Width | 21 cm |
| Volume | . 006 m³ |
| Shipping weight | . 66 KG |
Technical
| Component Type | Single Component |
|---|---|
| Fluid Orifice Size (cm) | 0. 318 |
| Fluid Orifice Size (mm) | 3. 17 |
| For use with | Project Painter Plus, X5, X7, ProX17 Stand, ProX17 Cart, ProX19 Stand, ProX19 Cart, ProX21 Stand, ProX21 Cart, Magnum A30 ProPlus, Magnum A45 ProPlus, Magnum A60 ProPlus, Magnum A80 ProPlus, Magnum A100 ProPlus, Magnum ProS19 ProPlus, Magnum ProS21 ProPlus |
| Gun Weight (oz) | 2 2 |
| Includes | TrueAirless 515 spray tip, spray tip guard, smooth glide swivel |
| Maximum fluid pressure (bar) | 2 48 |
| Maximum fluid pressure (kPa) | 2 4 800 |
| Maximum fluid pressure (psi) | 3600 |
| Model | SG3 |
| Overall height (cm) | 20. 32 |
| Overall height (in) | 8 |
| Overall height (mm) | 203. 2 |
| Overall Length (cm) | 4, 445 |
| Overall Length (in) | 1. 75 |
| Overall Length (mm) | 44. 45 |
| Overall width (cm) | 12. 7 |
| Overall width (in) | 5 |
| Overall width (mm) | 1 27 |
| Purge Method | L iquid |
| Series | Airless Gun |
| Trigger lock | L ocking |
| Trigger Type | Four -finger |
| Maximum fluid pressure (MPa) | 24. 8 |
