XD80™, air/water/diesel fuel, 25 mm (1") inlet/outlet, without accessories (25 mm x 46 m (1" x 150') capacity), NPT, 115 VAC electric motor, yellow
€6,728.26*
Ready for shipping in 5-8 Werktage
The innovative design of the XD60, XD70 and XD80 series motorised hose reels is packed with features to help you work safer, smarter and faster. Direct-drive motor options include hydraulic, pneumatic and electric motors for air, water, oil, grease, diesel fuel and synthetic oil, grease, diesel fuel dispensing and waste oil draining.
Ideal for indoor and outdoor use at heavy-duty vehicle dealerships, fleet maintenance, public garages, construction vehicle maintenance, agricultural vehicles and emergency vehicles.
- Safe, reliable direct drive and geared motors - The drive unit is clean and lubricated for life No need to worry about greasy, unprotected drive chains that require maintenance and can be dangerous for operators
- Easy system integration - Inlet and motor orientation can be easily changed for right or left side flow.
- Welded Rugged Reel - Built to support the weight of heavy hoses and to surround and protect the drive unit from the elements to ensure longer lasting and safer operation
- Robust and durable body - One-piece welded heavy duty frame - designed to flex under extreme operating conditions and is stronger than bolted frames which can loosen with use. Individually painted and powder coated components have better corrosion resistance than assembled and painted products
| Application: | Air, water, diesel fuel |
|---|---|
| Colour: | Yellow |
| Diffuser size (cm): | 2.54 |
| Frame type: | Box frame |
| Frequency (Hz): | 50/60 |
| Gender of the inlet thread: | Internal thread |
| Gender of the outlet thread: | Internal thread |
| Hose reel type: | Reel without accessories |
| Inlet size (cm): | 2.54 |
| Inlet size (inch): | 1 |
| Inlet size (mm): | 25.4 |
| Inlet thread type: | NPT |
| Maximum operating pressure (MPa): | 4.1 |
| Maximum operating pressure (kPa): | 4100 |
| Maximum operating pressure (psi): | 600 |
| Maximum temperature (°C): | 82 |
| Minimum temperature (°C): | -40 |
| Model: | XD |
| Operating voltage (V ac): | 115 |
| Outlet size (inch): | 1 |
| Outlet size (mm): | 25.4 |
| Outlet thread type: | NPT |
| Permissible operating pressure (bar): | 41 |
| Rated current (A): | 6.5 |
| Rated speed (rpm): | 500 |
| Recommended environment: | Indoor, For outdoor use |
| Recommended material type: | Air, water, diesel fuel |
| Reel thread type: | NPT |
| Series: | 80 |
| Single retractor: | 1 |
| Total height (cm): | 76.5 |
| Total height (mm): | 765 |
| Total length (cm): | 77 |
| Total length (mm): | 772 |
| Total width (cm): | 80.8 |
| Total width (mm): | 808 |
| Type: | Electric motor return hose reel |
- Product number: 1034482
- Manufacturer: Graco
- EAN: 00633955142701
- Weight: 97.975 kg
Further manufacturer information
- 332751G, Handbuch, Schlauchtrommeln XD 60™, XD 70™, XD 80™ mit Antrieb beim Aufrollen, Anleitungen (Deutsch)
- 332751G, Handbuch, Schlauchtrommeln XD 60™, XD 70™, XD 80™ mit Antrieb beim Aufrollen, Anleitungen (Italiano)
- 332751G, Handbuch, Schlauchtrommeln XD 60™, XD 70™, XD 80™ mit Antrieb beim Aufrollen, Anleitungen (Français)
- 332751G, Handbuch, Schlauchtrommeln XD 60™, XD 70™, XD 80™ mit Antrieb beim Aufrollen, Anleitungen (русский)
- 332751G, Handbuch, Schlauchtrommeln XD 60™, XD 70™, XD 80™ mit Antrieb beim Aufrollen, Anleitungen (中文)
- 332751G, Handbuch, Schlauchtrommeln XD 60™, XD 70™, XD 80™ mit Antrieb beim Aufrollen, Anleitungen (Español)
- 332751G, Handbuch, Schlauchtrommeln XD 60™, XD 70™, XD 80™ mit Antrieb beim Aufrollen, Anleitungen (English)
