Manufacturer no.:
24D792
SaniForce 6:1 carbon steel barrel drainage double ball piston pump package with exposed controls
Price on request
Ready for shipping in 5-8 Werktage
Also interesting
Product information
The quick-disassembly SaniForce 6:1 piston pumps from Graco are made of 300 series stainless steel. The air motor is easy to maintain, increases efficiency and reduces operating costs. Ideal for food, cosmetic and personal care applications
Quick-disassembly hygienic piston pump for food and personal care applications
SaniForce 6:1 hygienic piston pump:
- Flow rates of up to 15.1 l/min
- Maximum material pressure of 4.1 MPa (41 bar, 600 psi)
- With immersed suction cup up to 5,000 cps and up to 100,000 cps
- The most modern air motor on the market
- Available in versions with double ball or suction piston
- Liquid transfer and supply of low to medium viscosity liquid materials
- Suitable for pumping products such as Cosmetics, fruit juice concentrates, creamy candy fillings, ice cream flavours, jams and jellies
FDA-compliant cover
- Easily removable FDA-compliant shroud for cleaning and accessing the modular air valve - less downtime
- The quick-disassemble bottom pumps are made of 300 series stainless steel and guarantee a long service life
| Compatible drum height (cm): | 103.5 |
|---|---|
| Compatible drum height (inch): | 40.75 |
| Compatible drum height (mm): | 1035 |
| Compatible drum inner diameter (cm): | 60.96 |
| Compatible drum inner diameter (inch): | 24 |
| Compatible drum inner diameter (mm): | 609.6 |
| Control console material: | Normal steel |
| Control console type: | Open design |
| Finish/coating: | Lacquered |
| Frame material: | Normal steel |
| Material container volume (litres): | 200 |
| Material follower plate: | Normal steel |
| Maximum air supply pressure (bar): | 6.9 |
| Maximum air supply pressure (kPa): | 690 |
| Maximum air supply pressure (kg/cm²): | 07.03 |
| Maximum delivery rate (L/min): | 15.1 |
| Maximum height (cm): | 274.32 |
| Maximum height (m): | 2.75 |
| Maximum height (mm): | 2743 |
| Maximum inlet air pressure (psi): | 100 |
| Maximum material pressure (bar): | 44.8 |
| Maximum material pressure (kPa): | 4480 |
| Maximum material pressure (psi): | 650 |
| Maximum operating pressure (MPa): | 4.5 |
| Maximum operating pressure (kPa): | 4480 |
| Maximum operating pressure (psi): | 650 |
| Maximum viscosity (cP): | 75000 |
| Minimum height (cm): | 172.52 |
| Minimum height (m): | 1.73 |
| Minimum height (mm): | 1725 |
| Model: | SaniForce |
| Permissible operating pressure (bar): | 44.8 |
| Pump type: | Double ball |
| Standards met:: | FDA compliant materials |
| Total depth (cm): | 63.5 |
| Total depth (mm): | 635 |
| Total width (cm): | 106.7 |
| Total width (mm): | 1067 |
| Transmission ratio of the pump: | 6:1 |
| Type: | Barrel emptying device |
| Weight (kg): | 170.1 |
| Wetted material: | Neoprene, stainless steel, Buna-N, polypropylene, polychloroprene, nitrile rubber, nylon, UHMWPE |
More information
- Product number: 1030007
- Manufacturer: Graco
- EAN: 00633955161115
- Weight: 209.286 kg
- Length: 740 mm
- Width: 1380 mm
- Height: 1870 mm
