Manufacturer no.:
24Y203
LD™ series, oil, 13 mm (1/2") inlet, 1/2" X 35' (13 mm X 11 m) hose, BSPT, without mounting kit, without inlet kit, white
€325.58*
% €361.76* (10% saved)Ready for shipping in 5-8 days
Also interesting
Product information
Graco's one-piece enclosed hose reels keep the workplace organised and safe.
Designed for light-duty applications in sales offices, service and body shops and industrial manufacturing facilities.
- Large material connection - Maximises material flow with minimal pressure drop
- Easy spring tension adjustment - Spring tension can be easily increased or decreased when the retractor is pressurised.
- Complete housing - Robust, dent-proof, corrosion-resistant housing
| Application: | oil |
|---|---|
| Colour: | White |
| Frame type: | Housing |
| Hose length (m): | 11 |
| Hose reel type: | Reel with trousers |
| Inlet size (inch): | 1/2 |
| Inlet size (mm): | 12.7 |
| Inlet thread type: | NPT |
| Inner diameter hose (inch): | 1/2 |
| Inner diameter hose (mm): | 12.7 |
| Maximum operating pressure (psi): | 1800s |
| Maximum temperature (°C): | 60 |
| Outlet size (inch): | 1/2 |
| Outlet size (mm): | 12.7 |
| Recommended environment: | Interior |
| Recommended material type: | oil |
| Reel thread type: | NPT |
| Type: | Spring reel |
| Wetted parts: | mild steel, Buna-N, PTFE |
More information
- Product number: 1034645
- Manufacturer: Graco
- EAN: 00755652278153
- Weight: 11.5 kg
- Length: 590 mm
- Width: 500 mm
- Height: 210 mm
Technical details
Operating specifications
| UPC product | 755652278153 |
|---|---|
| Division | LED |
| Price Block | 148 |
| Country of origin | CN |
| Unit | EA |
| Height | 21 CM |
| Length | 59 cm |
| Width | 50 cm |
| Volume | 0 . 062 m³ |
| Shipping weight | 11.5 KG |
| HTS code (EU) | 39 1 7390099 |
| HTS code (GB) | 39 1 7390099 |
Technical
| Dry Weight (lb) | 30. 8 |
|---|---|
| Pipe inner diameter (mm) | 12. 7 |
| Inlet Size (in) | 1/2 |
| Inlet size (mm) | 12. 7 |
| Maximum temperature (°C) | 60 |
| Maximum temperature (°F) | 1 4 0 |
| Maximum working pressure (psi) | 1 8 00 |
| Outlet Size (in) | 1/2 |
| Outlet Size (mm) | 12. 7 |
| Frame Type | Enclosed |
| Reel thread type | BSPT |
| Recommended fluid type | Oil |
| Hose reel type | Reel with hose |
| Model | LD |
