Manufacturer no.: CM8A1C

Feeder, Check-Mate, 38:1, C/S, Severe Duty, 2" L20c Ram, panel for compressed air control, 20L C/S flat plate, PU single scraper

€8,745.79*

% €9,717.54* (10% saved)

Prices include VAT plus shipping costs

€7,349.40*

Price excl. VAT

Ready for shipping in 5-8 days

14 days free exchange

Free shipping within Germany

EU B2B: net prices with valid VAT ID

Also interesting

Product information

Graco feeders reliably deliver single component sealants, adhesives and other medium to high viscosity materials from pails or drums to dispensing systems.

Bulk dispenser for ambient temperature sealants, adhesives and other medium to high viscosity materials

20 litre (5 gallon) pail sizes offer the same proven technologies as the larger systems, but with smaller NXT air motors.
Graco L20c - A lightweight siphon ram on a chassis
Industry-first controls give you instant and critical information at the touch of a button
Quick bucket placement
Plate scrapers can be replaced in seconds
Quick disconnect, turnbuckle attachment and pump cartridge packs allow pump maintenance without removing it from the ram
High-quality, durable parts reduce maintenance time and maximise uptime

Ambient/hot-melting/hot-melting:	Not heated
Application:	Bonding, sealing, sealing, potting, encapsulation, injection molding, spraying, liquid conveying, unloading, underfilling
Container type:	Bucket
Control console material:	n.a.
Energy type:	Pneumatic
Material container volume (litres):	20
Material follower plate:	Normal steel
Maximum air supply pressure (bar):	6.9
Maximum air supply pressure (kPa):	690
Maximum air supply pressure (kg/cm²):	07.03
Maximum delivery rate (L/min):	3.4
Maximum height (cm):	175.26
Maximum height (m):	1.75
Maximum height (mm):	1752.6
Maximum inlet air pressure (psi):	100
Maximum material pressure (bar):	262
Maximum material pressure (kPa):	26200
Maximum material pressure (psi):	3800
Maximum operating pressure (MPa):	26.2
Maximum operating pressure (kPa):	26200
Maximum operating pressure (psi):	3800
Maximum operating temperature (°C):	49
Minimum height (cm):	111.76
Minimum height (m):	1.12
Minimum height (mm):	1117.6
Model:	Check Mate
Permissible operating pressure (bar):	262
Pump type:	Suction piston
Series:	L20c
Total depth (cm):	53.34
Total depth (mm):	533.4
Total width (cm):	55.88
Total width (mm):	558.8
Transmission ratio of the pump:	38:1
Type:	Feeding device

More information

Product number: 1034270
Manufacturer: Graco
EAN: 00633955499164
Weight: 97.848 kg

Technical details

Specifications

Operating specifications

UPC product	633955499164
Division	IPD
Price Block	2 22
Country of origin	US
Unit	EA
Height	0 CM
Length	0 CM
Width	0 CM
Volume	0 M3
Shipping weight	97.85 KG

Technical

Ambient/Warm Melt/Hot Melt	Ambi ent
Container Type	Pail
Material container volume (gal)	5. 3
Material Container Volume (l)	20
Maximum air inlet pressure (bar)	6. 9
Maximum air inlet pressure (kg/cm²)	7. 03
Maximum air inlet pressure (kPa)	690
Maximum air inlet pressure (psi)	100
Maximum flow rate (L/min)	3. 4
Maximum fluid pressure (bar)	2 62
Maximum fluid pressure (kPa)	2 6 200
Maximum fluid pressure (psi)	3800
Maximum height (cm)	175. 26
Maximum height (ft)	5. 75
Maximum height (in)	69
Maximum height (m)	1. 75
Maximum height (mm)	1752. 6
Maximum operating temperature (°C)	4 9
Maximum operating temperature (°F)	120
Maximum working pressure (bar)	2 62
Maximum working pressure (kPa)	2 6 200
Maximum working pressure (MPa)	26. 2
Maximum working pressure (psi)	3800
Minimum Height (cm)	111. 76
Minimum height (ft)	3. 67
Minimum height (in)	4 4
Minimum height (m)	1. 12
Minimum height (mm)	1117. 6
Model	Check-Mate
Overall Depth (cm)	53. 34
Overall depth (in)	2 1
Overall depth (mm)	533. 4
Overall width (cm)	55. 88
Overall width (in)	2 2
Overall width (mm)	558. 8
Ram material	Carbon steel
Series	L20c
