Product information
QUANTM is not just another electric pump: it's a game changer. QUANTM features a revolutionary electric motor design that lowers operating costs and provides the reliability you need to keep your production lines running. With multiple fluid path options in different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable replacement for your current less efficient pneumatic pumps or as the perfect solution for greenfield construction. The unique self-priming, sealless design provides a smooth and consistent flow and is the only electric diaphragm pump on the market that shuts down under pressure to reduce downtime due to pump failure caused by clogged lines or closed valves. QUANTM is designed to be quieter, more efficient and highly reliable while delivering energy savings that will significantly boost your sustainability reputation. It's time to rethink your pumping strategy and boost your bottom line by switching to a QUANTM electric pump.
Made entirely from aluminium, the fluid section is specifically designed to resist abrasion while offering lightweight corrosion resistance. With up to 8 times more continuous torque at low speeds than conventional motors, this general purpose electric pump is an energy-saving workhorse that is ideal for sump drainage applications as well as applications involving the evacuation of petroleum products (new and used oils) and the evacuation of solvents. This powerful new pump offers a higher level of reliability to minimise downtime, while the plug-and-play design allows for easy installation into any production line without additional investment or infrastructure rework. Not suitable for use with halogenated hydrocarbons.
Revolutionary design
  • Replace existing air-driven pumps with electric pump technology that switches off under pressure and features the AutoPrime function
  • Compact and efficient electric drive eliminates the gearbox and offers a comparable footprint to a pneumatic diaphragm pump
  • Up to 80 % reduction in energy consumption compared to pneumatic pumps, which reduces operating costs and quickly amortises the investment
  • Quiet operation reduces system noise and improves employee health and safety
  • Intelligent pump control provides more accurate flow setpoints and integrated I/O

Efficient electric motor
  • Powder coated aluminium electric drive
  • 240 VAC 1ph motor with 15 ft connection leads
  • ATEX Ex II 2 G EX dh IIB T4 Gb approval for hazardous areas

Materials of construction
  • Aluminium liquid section with NPT end connection
  • Internal components include PTFE seat, PTFE ball, two-piece PTFE/santoprene diaphragm and PTFE manifold O-ring


Graco is a globally recognised manufacturer of fluid handling systems and components. services for various industries. Graco's high-quality products are used for paints, coatings, lubricants, sealants, adhesives and building materials. With decades of expertise, Graco offers innovative solutions for efficient material handling and optimised coating applications and precise dispensing technology.
More information
  • Product number: 2146138
  • Manufacturer: Graco
  • EAN: 769946324204
  • Weight: 64 kg
  • Length: 8.3 mm
  • Width: 5.1 mm
  • Height: 8.5 mm

Technical details

Operating specifications
UPC product 7 6 9946324204
Division PRO
Price Block 2 52
Country of origin US
Unit EA
Height 85 CM
Length 83 CM
Width 51 cm
Volume . 36 m³
Shipping weight 64 kg
HTS code (GB) 8413508090
HTS code (EU) 8413508090
Technical
Fluid inlet size (in) 2
Fluid inlet size (mm) 51
Fluid inlet thread gender Female
Fluid outlet size (mm) 50. 8
Fluid outlet thread gender Female
Maximum amperage (A) 15
Maximum flow rate (L/min) 4 54
Maximum fluid pressure (bar) 4. 14
Maximum fluid pressure (kPa) 4 14
Maximum fluid pressure (psi) 60
Maximum solid size (in) 0. 25
Maximum solid size (mm) 6. 4
Model QU AN TM
Overall Height (in) 23. 6
Series i120
Maximum Ambient Temperature (°C) 104
Maximum fluid operating temperature (°C) 82
Minimum fluid operating temperature (°C) -40
Maximum fluid operating temperature (°F) 180
Minimum fluid operating temperature (°F) -40
Fluid Section Aluminum, End Port, NPT
Maximum Ambient Temperature (°C) 40
Cord Length (m) 4. 57
Cord length (ft) 15
Fluid passage size (in) 2
Fluid passage size (mm) 51
Configuration code QTE-ALFC4SAPTPSPTA100

Further manufacturer information

3A8572.pdf |3A7120G, Bombas QUANTM, Modelos industriales, Instrucciones, espaol |Spanisch |Revision G
3A8572.pdf |3A7117G, Pompes QUANTM, modles industriels, instructions, franais |Franzsisch |Revision G
3A8572.pdf |3A7161G, Bombas QUANTM, Modelos industriais, Instrues, Portugus |Portugiesisch |Revision G
3A8572.pdf |3A7162G, QUANTM-pumpar, industriella modeller, instruktioner, svenska |Schwedisch |Revision G
3A8572.pdf |3A7160G, QUANTM pumper, industrimodeller, instruksjoner, norsk |Norwegisch |Revision G
3A8572.pdf |3A7171G, QUANTM Pompalar, Endstriyel Modeller, Talimatlar, Trke |Trkisch |Revision G
3A8572.pdf |3A7150G, Pompe QUANTM, Modelli industriali, Istruzioni, Italiano |Italienisch |Revision G
3A8572.pdf |3A7149G, QUANTM Pumpen, Industriemodelle, Anleitung, Deutsch |Deutsch |Revision G
3A8572.pdf |3A7159G, QUANTM-pompen, Industrile modellen, Instructies, Nederlands |Niederlndisch |Revision G
3A8572.pdf |3A7091G QUANTM |Chinesisch |Revision LATEST
3A8572.pdf |3A7090G QUANTM , , , |Koreanisch |Revision LATEST
3A8572.pdf |3A8572H, QUANTM Pumps, Industrial Models, Instruction, English |Englisch |Revision LATEST
3A8572.pdf |3A7077G QUANTM |Japanisch |Revision LATEST
3A8946.pdf |3A7122G, Bombas QUANTM, modelos industriales, piezas, espaol |Spanisch |Revision G
3A8946.pdf |3A7121G, pompes QUANTM, modles industriels, pices, franais |Franzsisch |Revision G
3A8946.pdf |3A7101GQUANTM , , |Chinesisch |Revision LATEST
3A8946.pdf |3A7078G QUANTM |Japanisch |Revision LATEST
3A8946.pdf |3A8946H, QUANTM Pumps, Industrial Models, Parts, English |Englisch |Revision LATEST
3A8946.pdf |3A7100G, QUANTM , , , |Koreanisch |Revision LATEST
3A7637.pdf |3A7256E, QUANTM Elektrik Motoru, Tamir Paralar, Trke |Trkisch |Revision E
3A7637.pdf |3A7186F, Motore elettrico QUANTM, Riparazione-Parti, Italiano |Italienisch |Revision F
3A7637.pdf |3A7245F, QUANTM-elmotor, reparationsdelar, svenska |Schwedisch |Revision F
3A7637.pdf |3A7128F, QUANTM, Motor elctrico, Reparacin-piezas, espaol |Spanisch |Revision F
3A7637.pdf |3A7234F, QUANTM Motor eltrico, Reparao-Peas, Portugus |Portugiesisch |Revision F
3A7637.pdf |3A7127F, moteur lectrique QUANTM, pices dtaches, franais |Franzsisch |Revision F
3A7637.pdf |3A7208F, QUANTM Elektrisk motor, reparasjonsdeler, Norsk |Norwegisch |Revision F
3A7637.pdf |3A7175F, QUANTM Elektromotor, Reparatur-Teile, Deutsch |Deutsch |Revision F
3A7637.pdf |3A7197F, Elektrische QUANTM-motor, Reparatie-Onderdelen, Nederlands |Niederlndisch |Revision F
3A7637.pdf |3A7112FQUANTM |Chinesisch |Revision LATEST
3A7637.pdf |3A7637H, QUANTM Electric Motor, Repair-Parts, English |Englisch |Revision LATEST
3A7637.pdf |3A7076FQUANTM |Japanisch |Revision LATEST
3A7637.pdf |3A7111F, QUANTM , , |Koreanisch |Revision LATEST
