Nozzle sets & basic settings of the SATAjet 20 B
Which nozzle size suits filler, basecoat or clear? Practical guide to nozzle sets, gun inlet pressure, spray distance and fan width – incl. starting values and quick troubleshooting.
Learn more
Configurable according to:
Variants (37)
Price excl. VAT
Size:
11/16"
Price excl. VAT
selection:
roller
Variants
€7.64*
€33.85*
Price excl. VAT
Configurable according to:
Variants (4)
Price excl. VAT
Size:
cm 45 11/16"
Variants
€28.02*
€27.83*
Price excl. VAT
Variants
€23.74*
€19.95*
Price excl. VAT
Size:
0.018mm
|
angle:
50°
Price excl. VAT
Size:
0.019mm
|
angle:
30°
Price excl. VAT
Size:
0.012mm
|
angle:
30°
Price excl. VAT
Size:
0.035mm
|
angle:
40°
Price excl. VAT
Size:
11/16"
Price excl. VAT
Configurable according to:
Variants (38)
Variants
€142.65*
€119.88*
Price excl. VAT
Airless Nozzles & Nozzle Extensions
Discover Airless nozzles (tips), nozzle extensions and guards for professional and series applications. From fan angles and orifice sizes to pressure ranges and filter mesh through to material matching – we combine tip, guard and extension to suit the medium, flow rate and desired appearance.
Use & Benefits
High area output with a uniform spray pattern, clean edge profile and reduced overspray. The right combination of tip number, pressure, filtration and nozzle extension reduces overspray, improves ergonomics and delivers reproducible film builds.
Technology & Settings
The tip number defines the fan angle and orifice (e.g., 517 = ~25 cm at 30 cm distance, orifice 0.017″). Pressure ranges depend on material and orifice size; suitable filter grades (e.g., 30–200 mesh) prevent clogging. Reversible tips (RAC) make clearing blockages easy; guards and spacers keep fan geometry consistent. Nozzle extensions help maintain a constant spray distance on ceilings, walls and hard-to-reach areas.
Accessories & Integration
Tips (standard, fine-finish/low-pressure), guards, nozzle extensions (e.g., 25–100 cm), filters (inlet, gun, manifold), swivels, regulators/gauges as well as cleaning & testing media. We handle the compatibility check (thread/guard, tip series) and integration into your workshop and production line.
Advantages at a Glance
- Matching fan angle & orifice for your material window
- Consistent quality thanks to defined pressure & filtration settings
- Less overspray, higher coverage rate, ergonomic working
- Manufacturer-compatible with common Airless systems
Top Brands – Airless Program
- Graco – RAC/FFLP tips, guards & extensions.
- Wagner – tips, Airless guards & extensions.
- Anest Iwata – precise AirCombi tuning for repair & series.
- Titan – Airless tips & accessories for construction and industry.
- WIWA – industrial-grade tips, guards & filters.
- Sames – Airless components for serial processes.
- Binks – tips & guards for Airless applications.
- Walther Pilot – robust Airless components for continuous use.
- Ecco Finishing – precise stainless components & filtration technology.
- Krautzberger – reliable Airless accessory solutions.
- Larius – Airless accessories for construction & industry.
- QTech – Airless tips & extensions.
- TriTech – durable tips & guards for professionals.
- Colad – spare parts, accessories & consumables for spray guns and efficient coating processes.
- Mirka – abrasives, polishing products & cleaning accessories for optimal prep for spray-gun spare parts.
- Beschichtpunkt – specialist in application technology and spray-gun spare parts focused on precision, durability and high surface quality.
Go directly to Airless nozzles & nozzle extensions – or to consulting & compatibility check.
Guides & Resources
Processing basecoat with the SATAjet X 5500: speed, overlap, spray pattern
How to tune I-/O-air cap, walking speed and 50–70% overlap: uniform metallic laydown, clean edges and reproducible spray pattern – from edge zones to the finish.
Learn moreFrequently Asked Questions about Airless
What is an Airless nozzle (tip) and what are nozzle extensions used for?
Airless nozzles (tips) shape fan angle and flow rate without atomizing air. Nozzle extensions increase reach, make it easier to coat ceilings, floors and hard-to-access areas, and help maintain even overlaps at a constant spray distance.
How do I choose the right Airless nozzle (tip)?
Key factors are fan angle and orifice size (e.g., 517 = approx. 25 cm fan width at 30 cm distance, orifice 0.017″), material type/viscosity, desired surface appearance, recommended filter mesh and available pressure/flow. For fine finishes, choose smaller orifices and finer filters.
Which parameters influence the result in the Airless process?
Essential are the tip number (fan angle/orifice), system pressure, material temperature, hose length/diameter, filter grades (inlet, gun, manifold), guard/spacer and tip wear. They determine fan width, edge quality, material deposition, overspray and repeatability.
For which manufacturers are Airless tips, guards & nozzle extensions available?
We supply Airless nozzles (incl. reversible/RAC tips), guards and nozzle extensions for Graco, Wagner, Titan, WIWA, Sames, Binks, Walther Pilot, Ecco Finishing, Krautzberger, Larius, QTech and TriTech – including consulting on compatibility, pressure ranges and filter matching.
Customer Reviews
Request your Airless combination now
We support you in the selection of tip, guard & nozzle extension, the orifice/pressure setup and the compatibility check with your system – for safe, reproducible results.
Request now
